Potentiometer SP2 801 100 002 001

Angular Position Sensor Output Type = Resistive / Angle - Electrical ° = 100 / Angle - Mechanical ° = 360 / Resistance kOhm = 3 / Tolerance % = 20 / Linearity (±) % = 1 / Operating Voltage Max. V = 42 / Recommended Operating Wiper Current uA = 1 / Termination Type = Cable Terminal / Settable Torque Ncm = 0.2 / Mounting Type = Cable Mount / Protection Rating = IP54 / Operating Temperature Min. °C = -40 / Operating Temperature Max. °C = 150
