• Set using DIP switches: Independent for outputs 0 and 1 • Set using the Configurator: Independent for outputs 0 and 1
Allowable output load resistance
1 KΩ min.
600 Ω max.
Resolution
1/6,000 (FS)
Overall accuracy
25°C
±0.4% full scale
-10°C to 55°C
±0.8% full scale
Conversion time
2 ms/2 points
Converted data
Output ranges other than -10 to 10 V: Full scale is 0000 to 1770 hexadecimal (0 to 6,000) -10 to 10 V output range: Full scale is F448 to 0BB8 hexadecimal (-3,000 to 3,000) D/A conversion range: ±5% FS
Insulation method
Photocoupler isolation between outputs and communications lines (There is no isolation between output signals)
