SPECIFICATIONS
Product Series:ControlLogix (Bul. 1756 / 1757)
Component Type PLC & I/O:Analogue Input Module
Number of Analogue Inputs:16 qty
Analogue Input Type(s):Current / Voltage: Single-Ended / Differential, High Speed
Analogue Input Range(s):
-10 +10V DC
0 ... 5V DC
0 ... 10V DC
0 ... 20mA
Analogue Resolution, Input:16 bit (signed)
Module Specific Functions:ControlLogix voltage/current analog input module
Operating Temperature, Max:60 °C max
Operating Temperature, Min:0 °C min
Storage Temperature, Max:85 °C max
Storage Temperature, Min:-40 °C min
Relative Humidity, Max:95 %RH
Vibration Acceleration (Max.):2 m/s²
Vibration Frequency, Operational (Max.):500 Hz
Standards Compliance:
IEC 60068-2-1
IEC 60068-2-14
IEC 60068-2-2
IEC 60068-2-27
IEC 60068-2-30
IEC 60068-2-6
IEC 61000-4-2
IEC 61000-4-3
IEC 61000-4-4
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-6-4
