2 monitored in-/outputs selectable as detector line (collective Sie-mens/Cerberus PRO, Synova 600 or conventional Synova 300), as contact in-put, control output or as control output with acknowledgement
LED display of input and output status, fault, test, etc.
Control output for equipment 24 VDC, max. 2 A
Two-wire installation for all types of cable
Pluggable connection terminals
Power supply 24 VDC external (detection lines galvanically isolated)
Microprocessor-controlled signal evaluation
Communication via FDnet/C-
NET (individual addressing)
Applicable in dry, dusty and humid areas
Different mounting possibilities
