Dynamic Performance (PR9268/20x-x00 & PR9268/30x-x00）
Sensitivity
| 28.5 mV/mm/s (723.9 mV/in/s)
|
Frequency Range
| 4 to 1000Hz
|
Natural Frequency
| 4.5Hz ± 0.75Hz @ 20°C (68°F)
|
Transverse Sensitivity
| 0.13 (PR9268/20x-x00) @ 110Hz
0.27 (PR9268/30x-x00) @ 110Hz
|
Vibration Amplitude (Mechanical Limit)
| 3000µm (4000µm) peak-peak
|
Amplitude Linearity
| < 2%
|
Maximum Acceleration
| 10g (98.1 m/s2) peak-peak continuous
20g (196.2 m/s2) peak-peak intermittent
|
Maximum Transverse Acceleration
| 2g (19.62 m/s2)
|
Damping Factor
| ~0.56 @ 20°C (68°F)
~0.42 @ 100°C (212°F)
| Resistance
| 1875Ω ± 10%
| Inductance
| ≤ 90 mH
| Active Capacity
| < 1.2 nF
|
|
|
