Hand slide valve, VBOH-32-G14,1302994

Hand slide valve, VBOH-32-G14,1302994
Hand slide valve, VBOH-32-G14,1302994
  • MODEL: VBOH-32-G14
  • LEAD TIME: 3-4 weeks
$15.50
Add to Cart
Buy Now Ask Question
Add to Wish List Compare this Product

Product data sheet

  • Valve function3/2 double solenoid
  • Pneumatic connection, port 1G1/4
  • Pneumatic connection, port 2G1/4
  • Type of actuationManual
  • Type of mountingIn-line installation Screw-in
  • Standard nominal flow rate (standardised to DIN 1343)1675 l/min
  • Nominal size8.4 mm
  • Operating pressure-0.095 MPa ... 1.2 MPa
  • Operating pressure-0.95 bar ... 12 bar
  • Ambient temperature-10 °C ... 80 °C
  • Material housingAnodised wrought aluminium alloy
  • Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
  • Grid dimension31 mm
  • Instructions on useBitte nur Verschraubungen mit zylindrischem Gewinde einschrauben. Die Montage von konischem Gewinde kann das Gehäuse beschädigen und somit eine Klemmung bzw. Fehlfunktionen der Hülse verursachen.
  • Sealing principleSoft
  • Mounting positionoptional
  • DesignSleeve valve
  • Type of pilotingDirect
  • Flow directionReversible
  • Symbol00991286
  • Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
  • Corrosion resistance class CRC2 - Moderate corrosion stress
  • LABS (PWIS) conformityVDMA24364-B2-L
  • Media temperature-10 °C ... 80 °C
  • Actuating force45 N
  • Product weight35 g
  • Material screwed plugAnodised wrought aluminium alloy
  • Note on materialsRoHS-compliant
  • Material sealsNBR
