Dimensions
(Approx.)
(mm / inches)
A - Height : 1029mm / 40.5”
B - Width : 648mm / 25.5”
C - Depth : 483mm / 19”
Weight (Approx.) (Kg / Ibs) 62kg / 137Ibs
Principle of operation IPD Laser diode for optical detection
of actual particulates
International codes ISO 7 - 22
icountPD calibration By recognised online methods confirmed by
the relevent ISO procedures:
MTD - via a certified primary ISO 11171
automatic particle detector using ISO 11943
principles, with particle distribution reporting
to ISO 4406:1996
icountPD recalibration Every 12 months: conmoninfo@parker.com
Unit Ambient storage
temperature
-26˚C to +70˚C (-79˚F to + 158˚F)
Unit operating environment DO NOT use the filtration trolley in wet or
damp environmental conditions
Recommended fluid
operating viscosity
Up to 108 cSt (500 SUS)
(0.85 Specific Gravity)
Filter trolley operating
viscosity range
Use below 800 cSt (3880 SUS)
Pump Flow Rate 38 I/min (10 GPM)
1st stage filtration
(Suction / Inlet Filter)
Micron rating specified in part number, visual
indicator (Optional), 0.2 bar (3 psi) bypass
preventing pump cavitation
2nd stage filtration
(Pressure / Outlet Filter)
Micron rating specified in part number, visual
indicator, 1.7 bar (25 psi) prevents excessive
pressures
Suction / Pressure Hose PVC (Standard, 1 metre (39”)
Suction Pressure Wand PVC (Standard, 1 metre (39”)
Certification IP22 rating
EN61326-1-2006 Electrical equipment for
measurement, control and laboratory
EN61029-1-2009 + A11:2010 Modified
Safety of transportable motor operated
electric tools
2006/42/EC Machinery Directive
Construction Cart frame = Steel
Filter head = Aluminium
Filter bowl = Steel
Hoses = PVC (std.)
Wands = PVC (std.) Steel tube
Electrical Motor 10MFP - ¾ hp@ 3450 rpm, O.D.P.
Thermal overload protection
