trip
5 mm
Clamping surface
Ø 40
Installation location
Optional
Working mode
Single acting
Symbol
00991208
working pressure
≤0.6 Mpa
working pressure
≤6 bar
working pressure
≤87 psi
Working medium
Compressed air, in accordance with ISO 8573-1:2010 [7: -: -]
Paint Wetting Defect Substance (PWIS) Compliance
VDMA24364-B1/B2-L
Suitable for lithium-ion battery production
Do not use metals with copper content exceeding 5%. Exceptions: Printed circuit boards, cables, electrical plug connectors, and coils
ambient temperature
-10 °C ... 40 °C
Product weight
52 g
Installation method
With through-hole
Pneumatic interface
M3
Shell material
Die cast aluminum
Membrane material
TPE-U(PU)
